Product Details:
|
| Material: | Aluminium | Product Name: | 1500W Battery Charger |
|---|---|---|---|
| AC Input Operation Voltage Range: | 85V-265V | Output Power: | 1500W |
| Protection Level: | IP67 | Overall Size: | 282*124*72mm |
| High Light: | 10A 24v lithium battery charger,96V 24v lithium battery charger,84V lead acid battery charger lithium ion |
||
Lithium Battery Charger 96V 10A 84V 12A 72V 15A 60V 20A 48V 25A 36V 24V 30A Lead Acid LiFePO4 Lithium Battery Charger
Specifications:
| Parameter | |||
| Model: | OK-CH-1500 | Max Power: | 1500W |
| Shell: | Aluminium casting | Size: | 282*124*72mm |
| Net Weight: | 3.2kg | Packing: | 36*23*19cm/pcs |
| AC Input: | 85-145Vac/185-265Vac/85V-265Vac | Waterproof: | IP66 |
| Max Efficiency: | >=93% | Operating Temperature: | -30 to 65℃ |
| Storage Temperature: | -40 to 95℃ | Noise: | <=40dB |
| Cooling: | Active cooling with fan | ||
| Protection: | Input low-voltage&over-voltage protection, Overheat protection/Output empty-load protection, Output short&reverse protection, Output over-current&over-voltage protection, Automatic shutdown when fully charged | ||
Common Output:
| Common Output | |||||
| Model | Nominal Voltage | Lead Acid | LiFePO4 | NCA/NCM | Max Charge Current |
|
E15 |
12V | 14.7V | 14.6V | 16.8V | 30A@110Vac ,30A@220Vac |
| 24V | 29.4V | 29.2V | 29.4V | 30A@110Vac ,30A@220Vac | |
| 36V | 44.1V | 43.8V | 42V | 30A@110Vac ,30A@220Vac | |
| 48V | 58.8V | 58.4V | 58.8V | 20A@110Vac ,25A@220Vac | |
| 60V | 73.5V | 73V | 67.2V | 18A@110Vac ,20A@220Vac | |
| 72V | 88.2V | 87.6V | 84V | 15A@110Vac ,15A@220Vac | |
| 84V | 102.9V | 102.2V | 100.8V | 12A@110Vac ,12A@220Vac | |
| 96V | 117.6V | 116.8V | 117.6V | 10A@110Vac ,10A@220Vac | |
| Our chargers can be made for all kind of Lead acid and Lithium battery.We also can customize charging profile of output voltage and current according to your request.Please contact us to confirm more details. | |||||
Optional Functions
1,Communication Protocol: CAN BUS or RS485.
2,Auxiliary Power Supply 12V 0.3A
3,Temperature sensor in connector
4,Anti-motion loop
5,Extra Led indicator with cable
